LiFePO4 Rack Type Battery TPW4850-U
topway new energy (hcctop)
1.A.TPWJZ007
| Model | 48V 50Ah |
| Compound mode | 15S1P |
| Charging mode | 48V/5A |
| Voltage operating range | 48V(37.5-54.75V) |
| Nominal Capacity | 50Ah |
| Nominal battery capacity | 2400Wh |
| Max.continuous charge current | 10A |
| Max.continuous discharge current | 50A |
| Operation temperature | -20 ~ 65℃ |
| Cycle life | ≥2000 times |
| Size | 400*442*133mm（L*W*H） |
| Weight | about 35KG |
| Waterproof grade | IP54 |
Rack energy storage battery has the following advantages:
1, the modular design of the rack energy storage battery makes it easy to expand and maintain, adapting to different scales of energy storage needs.
2, rack energy storage battery occupies little space, can efficiently use the vertical space of the server room or warehouse, improve space utilisation.
3, rack storage batteries are usually equipped with highly integrated monitoring and management system, which can monitor the battery status in real time to ensure safety and stability.
4, rack storage battery installation flexibility, easy to quickly dock with the existing power system, reducing installation time and cost.
5, the rack structure design makes excellent heat dissipation performance, which helps to extend battery life and improve energy conversion efficiency.
| Model | 48V 50Ah |
| Compound mode | 15S1P |
| Charging mode | 48V/5A |
| Voltage operating range | 48V(37.5-54.75V) |
| Nominal Capacity | 50Ah |
| Nominal battery capacity | 2400Wh |
| Max.continuous charge current | 10A |
| Max.continuous discharge current | 50A |
| Operation temperature | -20 ~ 65℃ |
| Cycle life | ≥2000 times |
| Size | 400*442*133mm（L*W*H） |
| Weight | about 35KG |
| Waterproof grade | IP54 |
Rack energy storage battery has the following advantages:
1, the modular design of the rack energy storage battery makes it easy to expand and maintain, adapting to different scales of energy storage needs.
2, rack energy storage battery occupies little space, can efficiently use the vertical space of the server room or warehouse, improve space utilisation.
3, rack storage batteries are usually equipped with highly integrated monitoring and management system, which can monitor the battery status in real time to ensure safety and stability.
4, rack storage battery installation flexibility, easy to quickly dock with the existing power system, reducing installation time and cost.
5, the rack structure design makes excellent heat dissipation performance, which helps to extend battery life and improve energy conversion efficiency.
